Aluminum-Framed Storefronts

Topic Summary

Compared to curtain wall systems, storefront systems are typically designed to less stringent performance requirements and are composed of lighter-weight, simpler aluminum sections. The most commonly used systems have 2- x 4-inch framing members designed for center glazing with either monolithic or insulating glass.

Storefront framing may also be used for window-wall systems, ribbon-wall or strip-window systems, and punched openings. Operable window units, as well as spandrel and infill panels, may be incorporated into entrance and storefront systems.

Aluminum-framed sections may be non-thermal, thermally improved, thermally broken (thermal-barrier), or structurally glazed systems. Storefront framing systems can be field assembled and glazed.

Typical glazing systems for storefronts include conventional as well as two-sided, structural-sealant-glazed systems, sometimes referred to as butt-glazed. In conventional glazed systems, lites or panels are retained on all sides by continuous gaskets set into the framing members. In two-sided, structural-sealant-glazed systems, structural sealant adheres the glazing units to vertical framing members, and continuous gaskets hold the glass at horizontal members.

Finishes for aluminum framing members have traditionally included clear or color anodized and organic coating systems, such as Kynar-based coatings. Polyester powder paints now meet industry performance standards for durability and are available from some manufacturers. Due to their greater film thickness and abrasion resistance, powdercoat finishes are well suited for high traffic entrances and storefronts.
